Product dimensions
Size: 40m²
Thickness: 47mil (1.2mm)
Length: 20m Width: 2m
Package: Hard tube and polythene foil
Minimum order quantity 24 rolls.
The shipping cost is additionally calculated.
Ruvimat D12 – 20x2m
257.34 лв.
Product Description
Product details
Place of origin: Bulgaria, Europe
Brand: Ruvitex
Model: Ruvimat D12
Description
Ruvimat D12 is a Tri-Ply (three-layer) polymer membrane based on a high quality plasticized polyvinylchloride (PVC) and a built-in reinforcement polyester grid.
Dimensions
Thickness: 1.2mm
Length: 20m
Width: 2m
Characteristics and Advantages
- Watertight
- Long life
- Recyclable
- UV Resistant
- Agressive liquids resistant
- Easy, fast and safe installation
- High vapor permeability
- Excellent flexibility on negative temperatures
- Resistant to micro-organisms
- Volume stability on big temperature differences
- High toughness and tension index
- Good peeling strength for welding.
- Flame retardant character.
Appearance
Surface: Matte
Color: Light grey (RAL7047)
Custom colors of the upper layer available for purchases of 4000m² and above
Package
Package type: Hard tube and polythene foil
Roll weight: 60kg
-
- Russia
-
- Ukraine – Porsche
-
- Spain
-
- Belgium
-
- England
-
- Romania
| Regulatory Document | EN 13956: 2012 | |
|---|---|---|
| Appearance deffects | missing | БДС EN 1850-2 |
| Lenght | 20m (-0%/+5%) | БДС EN 1848-2 |
| Width | 2m (-0.5%/+1%) | БДС EN 1848-2 |
| Straightness | ≤30mm | БДС EN 1848-2 |
| Flatness | ≤10mm | БДС EN 1848-2 |
| Thickness | 1.2mm (-5%/+10%) | БДС EN 1849-2 |
| Weighing | 1,45kg/m² (-5%/+10%) | БДС EN 1849-2 |
| Watertight | Yes | БДС EN 1928 method B |
| Reaction to fire | Class E (БДС EN ISO 1925-2 | Classification by БДС EN 13501-1 |
| Joints peel resistance | ≥300N/50mm | БДС EN 12316-2 |
| Joints shear resistance | ≥800N/50mm | БДС EN 12317-2 |
| Coefficient of vapor diffusion | 20 000 ± 30% µ | БДС EN 1931 |
| Tensile strenght | БДС EN 12311-2 method A |
|---|---|
| Lengthwise | ≥800N/50mm |
| Across | ≥800N/50mm |
| Tear resistance | БДС EN 12310-2 |
|---|---|
| Lengthwise | ≥180N |
| Across | ≥180N |
| Size temperature stability (80°C/6h) | БДС EN 1107-2 |
|---|---|
| Lengthwise | ±1% |
| Across | ±1% |
Additional Information
| Length: | 20m |
|---|---|
| Width: | 2m |
| Size: | 40m² |
| Thickness: | 47MIL (1mm) |
